- Deburr Master®
tools are constructed with precision machined, solid tool steel and can be
used on machines such as single or multi-spindle drilling machines,
lathes, NC machine tools, machining centers as well as hand tools. Each
tool is fitted with a replaceable standard blade made of high-speed steel
in Double Action (DA), unless otherwise specified. Special tools and
sizes are available. Please submit a blueprint for quotation.
Type A Tool
Type B Tool
Type C Tool
Deburr Master Tool Set
-
- The Elipto-Master®
is suitable for use with low speed drills, drill presses, and automatic
machinery. Only light pressure is necessary to generate the cutting action
of the Elipto-Master®. The
unique design of Elipto-Master®
features a conically-shaped pilot, which allows for easy direction into
the drilled hole. The self-centering, spring-loaded pilot seats itself at
a point corresponding to the hole diameter. Thus establishing a rotational
axis for further advance of the tool and entry of the cutter. This action
will produce a chamfer of relative conformity.
Speed and ease of operation are achieved through a
unique design feature of the Elipto-Master®,
which allows the cutter to follow the surface configuration of the hole
without manual guidance.
The Elipto-Master®
body is made of hardened ground steel. Cutter blades are of high-speed
steel, heat-treated, finish-ground and then surface-treated for added wear
resistance. Operational range of the tool is determined by pilot diameter
and not by cutter width.
EM-5 Tool
EM-8 Tool
EM-16 Tool
|
